Fire Alarm Panel Altay, 2 Zones
Product Brief:
Technical Information – Altay 2-Zone Fire Alarm Panel
Product Name: Altay Fire Alarm Panel, 2 Zones
Application: Designed for fire alarm system installation and control in small to medium-sized buildings.
✅ Main Features:
-
2 Fire Alarm Loops (Zones): Independent detectors can be connected to each loop.
-
1 Central Monitoring Output: Operates in “FIRE” or “SECURITY” mode.
-
4 Outputs (Relay/Siren): Connects to visual and audible alarm devices.
-
Notification Line Monitoring: Automatically detects line breaks and short circuits.
-
Power Supply Input: ~110V to 245V AC.
-
Built-in Backup Power Supply (UPS): Supports 12V/2.3Ah battery.
-
Battery Test Function: Both automatic and manual battery testing available.
-
LED Indicators: Easy monitoring of system and zone status.
-
Mounting: Wall-mounted design.
✅ Suitable For:
-
Hotels
-
Office buildings
-
Warehouses
-
Small shops
-
Schools and educational centers
